Tapping Home > Tapping > METRIC THREAD TAPS > FORMING TAPS
METRIC ROLL FORM
  PLUG STYLE - Plug with Oil Groove
Size Threads
per Inch		 Limit Bright TiN TiCN
EDP No. EDP No. EDP No.
M3 0.5 D5 Z8205 ZA205 ZC205
M4 0.7 D6 Z8246 ZA246 ZC246
M5 0.8 D7 Z8287 ZA287 ZC287
M6 1.0 D8 Z8318 ZA318 ZC318
M8 1.25 D9 Z8369 ZA369 ZC369
M10 1.5 D10 Z8420 ZA420 ZC420
M12 1.75 D11 Z850A ZA50A ZC50A


  BOTTOMING STYLE - Bottoming with Oil Groove
Size Threads
per Inch		 Limit Bright TiN TiCN
EDP No. EDP No. EDP No.
M2 0.4 D3 Z9133 ZB133 ZD133
M3 0.5 D5 Z9205 ZB205 ZD205
M4 0.7 D6 Z9246 ZB246 ZD246
M5 0.8 D7 Z9287 ZB287 ZD287
M6 1.0 D8 Z9318 ZB318 ZD318
M8 1.25 D9 Z9369 ZB369 ZD369
M10 1.5 D10 Z9420 ZB420 ZD420
M12 1.75 D11 Z950A ZB50A ZD50A
