i-Xmill CORNER RADIUS HOLDERS, STEEL(STRAIGHT NECK TYPE)
|
|
|
|
|
|
|
|
 i-Xmill Corner Radius Holders - Steel : Straight Neck Type |
| MILL DIAMETER(D1) |
EDP No. |
SHANK DIAMETER(D2) |
NECK DIAMETER(D3) |
LENGTH OF CUT(L1) |
LENGTH BELOW SHANK(L3) |
OVERALL LENGTH(L2) |
LENGTH TYPE |
WRENCH |
SCREW |
| 1/2 | ZRS1032 | 1/2 | 7/16 | 17/32 | 1*3/16 | 4*3/8 | Regular | TWF10 | TX1210 |
| 5/8 | ZRS1040 | 5/8 | 19/32 | 5/8 | 2 | 5*1/8 | Regular | TWF15 | TX1615 |
| ZRS2040 | | | | 2*9/16 | 6*1/2 | Intermediate | | |
| 3/4 | ZRS1048 | 3/4 | 23/32 | 23/32 | 2*3/8 | 5*1/2 | Regular | TWB20 | TX2020 |
| ZRS2048 | | | | 3*1/8 | 7*1/8 | Intermediate | | |
| 1 | ZRS1100 | 1 | 31/32 | 29/32 | 2*3/4 | 5*15/16 | Regular | TWB25 | TX2525 |
| ZRS2100 | | | | 3*9/16 | 8 | Intermediate | | |
| 1*1/4 | ZRS1116 | 1*1/4 | 1*7/32 | 1*1/8 | 3*1/8 | 6*5/16 | Regular | TWB30 | TX3030 |
| ZRS2116 | | | | 4 | 8*11/16 | Intermediate | | |
Unit:Inch
| i-Xmill Corner Radius Holders - Steel : Straight Neck Type |
| MILL DIAMETER(D1) |
EDP No. |
SHANK DIAMETER(D2) |
NECK DIAMETER(D3) |
LENGTH OF CUT(L1) |
LENGTH BELOW SHANK(L3) |
OVERALL LENGTH(L2) |
LENGTH TYPE |
WRENCH |
SCREW |
| 12 | ZRS1120 | 12 | 11 | 13 | 30 | 110 | Regular | TWF10 | TX1210 |
| 16 | ZRS1160 | 16 | 15 | 15 | 50 | 130 | Regular | TWF15 | TX1615 |
| ZRS2160 | | | | 65 | 165 | Intermediate | | |
| 20 | ZRS1200 | 20 | 19 | 18 | 60 | 140 | Regular | TWB20 | TX2020 |
| ZRS2200 | | | | 80 | 180 | Intermediate | | |
| 25 | ZRS1250 | 25 | 24 | 23 | 70 | 150 | Regular | TWB25 | TX2525 |
| ZRS2250 | | | | 90 | 200 | Intermediate | | |
| 30 | ZRS1300 | 32 | 29 | 27 | 80 | 160 | Regular | TWB30 | TX3030 |
| ZRS2300 | | | | 100 | 220 | Intermediate | | |
| 32 | ZRS1320 | 32 | 31 | 28 | 80 | 160 | Regular | TWB30 | TX3030 |
| ZRS2320 | | | | 100 | 220 | Intermediate | | |
Unit:Metric
|
|
 |
|
