i-Xmill BALL HOLDERS, CARBIDE(STRAIGHT NECK TYPE) - For Ball or Corner Radius Inserts

  i-Xmill Ball Holders - Carbide : Straight Neck Type
MILL DIAMETER
(D1)		 EDP No. SHANK DIAMETER
(D2)		 NECK DIAMETER
(D3)		 LENGTH OF CUT
(L1)		 LENGTH BELOW SHANK
(L3)		 OVERALL LENGTH
(L2)		 LENGTH TYPE WRENCH SCREW
5/16 ZBCB020 5/16 19/64 1/2 1*9/16 5*1/8 Long TWF07 TX0807
3/8 ZBCB024 3/8 23/64 5/8 2 5*1/2 Long TWF08 TX1008
1/2 ZBCB032 1/2 31/64 11/16 2*3/8 5*15/16 Long TWF10 TX1210
5/8 ZBCB040 5/8 39/64 13/16 3*3/16 7*15/16 Long TWF15 TX1615
ZBCD040 9*7/8
3/4 ZBCB048 3/4 47/64 1 3*3/16 7*15/16 Long TWB20 TX2020
ZBCC048 4 9*7/8
1 ZBCB100 1 63/64 1*3/16 4*3/4 9*7/8 Long TWB25 TX2525
1*1/4 ZBCB116 1*1/4 1*15/64 1*9/16 5*15/16 11*7/8 Long TWB30 TX3030
Unit:Inch

  i-Xmill Ball Holders - Carbide : Straight Neck Type
MILL DIAMETER
(D1)		 EDP No. SHANK DIAMETER
(D2)		 NECK DIAMETER
(D3)		 LENGTH OF CUT
(L1)		 LENGTH BELOW SHANK
(L3)		 OVERALL LENGTH
(L2)		 LENGTH TYPE WRENCH SCREW
8 ZBC1080 8 7.7 12 25 130 Long TWF07 TX0807
10 ZBC1100 10 9.7 15 30 140 Long TWF08 TX1008
12 ZBC1120 12 11.7 17 35 150 Long TWF10 TX1210
16 ZBC1160 16 15.7 20 50 200 Long TWF15 TX1615
20 ZBC1200 20 19.7 25 60 200 Long TWB20 TX2020
25 ZBC1250 25 24.7 30 75 200 Long TWB25 TX2525
30, 32 ZBC1320 32 29.7 40 90 250 Long TWB30 TX3030
Unit:Metric
