Drilling	Home > Drilling > CENTER DRILL

HSS(M2) REGULAR LENGTH WITH 60 DEGREE POINT

HSS(M2) REGULAR LENGTH CENTER DRILL WITH 60' POINT

Size	Diameter	Shank	Drill	Overall	EDP NO
Size	Diameter	Diameter	Length	Length	EDP NO
1	3/64	1/8	1/16	1-1/2	D1C90079
2	1/16	3/16	5/64	1-3/4	D1C90080
3	3/32	1/4	1/8	2	D1C90081
4	1/8	5/16	5/32	2-1/4	D1C90082
5	3/6	7/16	1/4	2-1/2	D1C90083
6	7/32	1/2	7/32	3	D1C90084

1	3/64	1/8	3/64	1-1/4	D1C90141
2	5/64	3/16	5/64	1-7/8	D1C90142
3	7/64	1/4	7/64	2	D1C90143
4	1/8	5/16	1/8	2-1/8	D1C90144
5	3/16	7/16	3/16	2-3/4	D1C90145
